|Product Name:||6 PET Button Sound Module||Dimension:||95*35*6 Mm|
|Application:||With Custom Voice||Plastic Housing:||Our Mold, Any Pantone Color|
|Materials:||ABS + Metal||Power:||AG10 * 3PCS|
6 PET Button Sound Module For Baby Sound Board Book, Funny Sound Book
2 layers of 400gsm~450gsm C1S,each page with a special fabric
Content:5 inner spread text + cover, 4C+4C printing
Finishing: UV varnishing and glossy lamination
Please note that we do not produce the book ourself, we are a sound module factory so only produce the sound module . However, if you need us to purchase book or provide some of our cooperated printers information ,its also ok.
(2) Sound Module:
1. Module size: 95*35*6mm (this is our mold ,we also have a similar exsiting mold with this one,please see the blew picture)
2. Sticker: 157GSM art paper *1pc
3. Batteries:3PCS *AG10 batteries, 6.0V operating voltage; Battery life cycle: 500~560 cycles,
Storage time: 2-3 years.
4. With standard sound or custom voice, such as the animals sound, transportation sound, melody
voice, human talking voice
5. Up to Volume standards for children's books: 75-85 dB
6. 27mm speaker *1pc
7.Operating:Installed this sound module onto the books,when opening the each page ,and touch the fabric which comes out a sound.
7.All the materials are non-toxic and environmentally-friendly, and can pass CE/ROHS/EMC/EN71-3.Besides we could provide all the raw materials SGS testing reports.
8. Sample ready time: 7 working days after received the custom sound
More detailed information about our exsiting molds for 6 Button Sound Modules
|1.Item||6 Button Sound Module (The button number & layout can be changed)|
|2.Material||ABS + art paper|
AG 10 * 3 PCS
1pcs 157gsm art paper,4C
1pc 27mm speaker,8Ω
|4.IC duration||3~5seconds per button,20seconds in total.(this can be changed according to your sound files)|
|5.Operating||Each button stands for one sound.Installed this sound module onto the books,when opening the each page ,and touch the fabric which comes out a sound.|
|6.Payment term||T/T, 30% deposit +70% balance money paid before the shipment.|
|7.Production time||30-45days after the sample approved(the first 10-15days for booking materials ,the next 10-15days for production,the final 10-15days for ready for shipment )|
|8.Package||Customized package,according to your requirements.|
1.Quote in 2 working days when received the enquiry
2.Exellent design as customer's requirment
3.For the sample charge, it will be returned back to you when playing an order.
4.OEM Manufacturer,OEM design & custom shape & custom sound are welcome.
5.Profession technology team to solve all skillful problems
6.Strict and carefully quality checking before shipping
7.If any quality problem please don't hesitate to call us at (86)0755-28791270
